CDI S10
Introducing maximum unrivalled mobility & unique zero set up time ‘’operating mode is transport
mode’’. The CDI S10 is fitted with an aggressive 2 bearing screenbox which can be adjusted in
speed, amptitude and direction to suit all application needs for maximum efficiency.
Specifications
Machine Weight: Approx. 1.9 Tonne (Basic Spec)
Output: Up to 40 TPH
Power unit: 17 Kw Diesel/Hydraulic (Onboard)
Tracks: 220mm (9”) wide
Discharge conveyor: 750mm wide (fully skirted)
Screenbox size: 1.52m x 0.9m (5’ x2’10”) (single deck Std)
(Optional 2 Deck version also available to maximise fines output)
Engine: Start/stop with manual throttle
Screenbox: hydraulic on/off
Discharge Conveyor: Hydraulic on/off (variable speed)
Tracks: Variable speed (Independent forward and reverse)
2 deck screenbox.
150mm high 90O swivel turntable
for tracks (manual slewing) Oversized discharged chutes
Remote Radio track control
Piano wire cassette tension frame
