Description
BIZON-450 Trackrd Jaw Crusher is the most powerful and advanced model in the BIZON crushing equipment series. The machine combines very high efficiency with versatile applications and reliable performance when processing a wide range of mineral and construction raw materials.
The BIZON-450 Tracked model is equipped with a track platform, which significantly increases the mobility and operational flexibility of the device. The crusher can be easily moved directly at the worksite, on a construction site, in a quarry, or in demolition zones.
The tracked chassis provides excellent traction even on uneven and difficult terrain, helping to reduce raw material transportation costs. Thanks to this, the BIZON-450 PRO is perfectly suited for crushing material directly at the extraction or dismantling site.
Compared to smaller models in the BIZON series, the 450 Tracked version allows processing of large blocks up to 450 mm in length and up to 250 mm in height and width. If a very fine fraction below 10 mm is required, a two-stage system is recommended, where the material is initially crushed to 50–80 mm and then reduced further in the next stage.
The key working elements – jaws – are available, depending on your choice, in EN-GJL-250 gray cast iron (standard, included in the set) or Mn18Cr2 high-manganese steel. These materials are characterized by high resistance to abrasion and impacts. For softer materials, such as brick or ceramics, gray cast iron jaws are recommended. For crushing hard materials, such as fieldstone or granite, jaws made of high-manganese steel are recommended.
Applications
The BIZON-450 Tracked crusher is used in:
- construction and recycling of construction waste
- mining industry
- production of construction materials
- chemical industry
The device is suitable for primary and secondary crushing of minerals and construction waste such as stone, concrete, brick, or synthetic materials with a compressive strength of up to 320 MPa.
Advantages
- Simple and durable design with easy maintenance
- High degree of crushing and uniform end product quality
- Economical operation and low operating costs
- Reduced noise and dust emissions
Technical specifications
- Engine: Vanguard (USA)
- Drive type: hydraulic
- Hydraulic oil capacity: 36 l
- Pump: CASAPPA HYDRAULICS
- Crusher base: hydraulic track drive
- Feed opening: 450 x 250 mm
- Drive: 14 HP petrol engine
- Crusher type: jaw
- Number of jaws: 6
- Crushed material: ore, coal, coke, granite, ceramics, quartz, concrete, aggregate
- Discharge hopper: yes
- Loading hopper: no
- Feed opening dimensions: 450 x 250 mm
- Warranty period: 12 months
